Sand Dryer

Sand drying machine is also known as Sand dryer, sand rotary dryer. Sand dryer is a kind of material handling a large dryer.Due to the reliable operation, simple operation, strong adaptability......

Scope of application:
Widely used in mining, building materials, chemicals, metallurgy, slag, clay and other industries.

Chat Now Send E-mail

Product Description

Feature Table Parameters Service Support

Product Description

Sand drying machine is also known as Sand dryer, sand rotary dryer. Sand dryer is a kind of material handling a large dryer. Due to the reliable operation, simple operation, strong adaptability, large capacity, energy saving and environmental protection, small investment, quick effect, widely used in building materials, chemical, foundry, wall insulation, etc., can adapt various fuels, such as coal, oil, gas, and so.

Feature

1.Equipment investment is wind foreign imports by 20%, manganese wear-resistant plate manufacturing, than ordinary steel wear 3-4 times.

2.The initial moisture content of 15%, final moisture to ensure that 0.5-1% is the following, is a cement plant slag powder, dry and wet mortar production line and other kinds of drying engineering preferred products.

3.Wheeled cement kiln (cement kiln) for preparing dry and wet clinker.

4.Rotary Kiln (Mining Chemistry): Magnetization and Oxidation of Roasted Iron Ore in Steel Plants

5.Wheel kilns use high-strength aluminum ore for roasting in plant smelting.

6.Rotary kilns used in aluminum alloy barbecue factories, chrome plated barbecue factories in chemical factories, and powder factories.

7.Rotary kilns (lime kilns) are used for active calcification of lime and dolomite in steel and ferroalloy plants.

Table Parameters

Equipment specification		φ2.0×6m	φ2.5×6.5m	φ2.7×7m	φ3×7m	φ3.2×7m	φ3.6×8m	φ4.2×8.5m
Cylinder diameter (m)		2.0	2.5	2.7	3	3.2	3.6	4.2
Cylinder length (m)		6	6.5	7	7	7	8	8.5
Volume of cylinder (m3)		18.84	31.89	40.5	49.46	56.26	81.38	118
Cylinder speed (rpm)		3-10	3-10	3-10	3-10	3-10	3-10	3-10
Residence Time (min)		12-30	12-30	12-30	12-30	12-30	12-30	12-30
Water Content (%)		6-25	6-25	6-25	6-25	6-25	6-25	6-25
Material End Water (%)		≤1	≤1	≤1	≤1	≤1	≤1	≤1
Max intake temperature (℃)		750-900℃	750-900℃	750-900℃	750-900℃	750-900℃	750-900℃	750-900℃
Capacity (T/H)	slag	20-25	25-30	30-35	35-10	40-45	50-65	70-85
	fly ash	10-17	17-21	20-25	23-27	25-30	30-45	45-63
	Sand	20-27	25-40	27-45	30-45	35-50	55-75	75-99
Motor model		Yr160m-4	Yr132m-4E	Yr160m-4	Yr160m-4	Yr132m-5E	Yr160m-4E	Yr160m-4E
Motor power (kw)		7.5×2	11×2	7.5×4	7.5×4	11×4	15×4	18.5×4
Reducer model		XWD-6	XWD-6	XWD-6	XWD-6	XWD-6	XWD-8	XWD-8
Speed Ratio (I)		17-29	17-29	17-29	17-29	17-29	17-29	17-29
Equipment weight (T)		25	32	35	38	43	57	77
