European version jaw crusher

European Type Jaw Crusher adopts world-class technology and high-end raw materials, which can crush hard stones or ores. Based on advantages of excellent quality, large output and long service life, which has already become the most popular equipment.....
Scope of application:
Mining, metallurgy, construction, highway, railroad, and water conservancy, etc.
Share With:
Product Description
European Type Jaw Crusher adopts world-class technology and high-end raw materials, which can crush hard stones or ores. Based on advantages of excellent quality, large output and long service life, which has already become the most popular equipment in the world without controversy. this machine can be widely used in mining machinery, road, construction metallurgy, etc.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.
Feature
●     1. Suitable for toughest material condition.
●     2. Simplicity and reliability.
●     3. Wide range of closed side setting adjustment.
●     4. Proven superior metallic ceramic jaw plates, Starry SkyTM, 50-80% more spares service life, low cost per ton.
●     5. Large capacity and low operation cost.
●     6. Makes adjustment operation much easier.



yuanli
Table Parameters
Model Maximum feed size (mm) Capacity (tph) Power KW (HP) Dimension (L×W×H) (mm) Weight (t)
PEW200×1300 150 12-35 30(40) 1320X2150X1176 6
PEW250×1000 220 15-50 30(40) 1400X1850X1310 6
PEW250×1200 220 20-50 37(50) 1450X2150X1175 7
PEW400×600 350 15-70 37(50) 1920X1460X1840 7.5
PEW760 620 150-350 110(150) 2950X2360X2760 24
PEW860 720 200-500 132(175) 3300X2320X3120 32
PEW1100 940 300-650 185(250) 4140X2660X3560 59.2
Service Support


- 48-hour idling test machine before leaving the factory.

- You can take the materials to the factory test machine.

- We will customize the solution according to your needs.
yuanli
Inquiry
Please feel free to submit your inquiry information to us. We will contact with you as soon as possible.
