Hammer Crusher

Hammer crusher is a kind of single-stage crusher that directly crushes materials with a particle size of 600-1200 mm to below 35 mm. Hammer crusher is widely used in the work of mine......
Scope of application:

Share With:
Product Description
Hammer crusher is a kind of single-stage crusher that directly crushes materials with a particle size of 600-1200 mm to below 35 mm. Hammer crusher is widely used in the work of mine, smelting, building material, road, railway, irrigation, chemical industry, etc. In addition, hammer crusher can also adjust the purlin gap to change the granularity of discharge size according to users’ requirements, in order to meet the different needs of different users.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.

Feature
●     1. Simple structure, convenient maintenance.
●     2. High crushing ratio, even output granularity.
●     3. High Capacity, low Cost.
●     4. Excellent performance, less dust.
●     5. High reduction ratio in the secondary crushing stage.
●     6. Final grain with high cubic grain proportion.



yuanli
Table Parameters
Specification Capacity(m³/h) Motor Power (kw)
PCΦ400×300 5-10 4P 11KW
PCΦ600×400 10-22 4P 22KW
PCΦ800×600 18-40 6P 55KW
PCΦ1000×800 25-50 8P 75KW
PCΦ1000×1000 30-55 8P 90KW
Service Support


- 48-hour idling test machine before leaving the factory.

- You can take the materials to the factory test machine.

- We will customize the solution according to your needs.
