Flotation machine

Flotation machinery can separate colored and ferrous metal mineral, and those non-metals such as fluorite, talc can also be processed by this machine.

Scope of application:
The machine can be used to separate nonferrous metal, ferrous metal, noble metal, nonmetallic mine, chemical material and recycle mine.

Chat Now Send E-mail

Share With:

Product Description

Feature Table Parameters Service Support

Product Description

Flotation machinery can separate colored and ferrous metal mineral, and those non-metals such as fluorite, talc can also be processed by this machine. Flotation machinery takes advantages of outstanding performance, easy adjusting and good stability.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.

Feature

● 1. Long life from liners of special alloy manganese steel.

● 2. The interior of the crusher is protected from dust by a self-lubricating seal ring.

● 3. Quiet operation and long life thanks to bevel gears with hardened, spiral-cut teeth.

● 4. Product curve and capacity can be optimized by adjusting the eccentric bushing supplied with the crusher.

● 5. High reduction ratio in the secondary crushing stage.

● 6. Final grain with high cubic grain proportion.

Table Parameters

Model	Volume (m3)	Capacity (m3/min)	Impeller dia (mm)	Impeller revolution (r.p.m)	Air pressure of blower (KPa)	Max of air Filling (m3/m2)	motor power (kw)
Model	Volume (m3)	Capacity (m3/min)	Impeller dia (mm)	Impeller revolution (r.p.m)	Air pressure of blower (KPa)	Max of air Filling (m3/m2)	Impeller	Scraper
KYF-1	1	0.2~1	340	281	≥12.6	2	4	1.1
KYF-1.2	1.2	0.2~1.2	410	247	≥12.8	2	7.5	1.1
KYF-2	2	0.4~2	410	247	≥14.7	2	7.5	1.1
KYF-3	3	0.6~3	480	219	≥19.8	2	7.5	1.5
KYF-4	4	1.2~4	550	200	≥19.8	2	11	1.5
KYF-8	8	3~8	630	175	≥21.6	2	15	1.5
KYF-16	16	4~16	740	160	≥25.5	2	30	1.5
KYF-24	24	4~24	800	150	≥30.4	2	30	1.5
KYF-38	38	10~38	880	138	≥34.3	2	37	1.5
